DESCRIPTION OF THE DEVICE
Front
(1) Screw thread for TPC-10 coupler for trussing
installation
(2) Stand sleeve
Rear
(5) DMX-input
(6) DMX-output
(7) LED Display with programming buttons
(8) Microphone
(9) Fixation screw for stand sleeve
(10) Fuseholder
1
5
6
7
8
1: Ground
2: Signal (–)
3: Signal (+)
MIC
MODE
UP DOWN ENTER
DMX IN
DMX OUT
13
2
3
1
4
(3) Infrared sensor for the remote control
(4) Spots with RGBAW LEDs
9
10
11
12
FUSE
F1A/250V
POWER OUT
POWER IN
100-240 V AC, 50/60 Hz
15
14
(11) Power input
(12) Power output
(13) Power connection for the control unit
(14) Power connection for the spots
(15) Fixation screws
23/36
13
00107903.DOC, Version 1.1
