Pillow Screen Installation
Corner Unit
LH
RH
NOTE: Corner screens
are 1" (25mm) wider
than straight screens
to close the corners.
13.25" (336mm)
13.25" (336mm)
3
Straight
2x
NOTE: Center screen on unit to yield equal
and parallel side gaps to adjacent screens.
NOTE: Do not over-tighten.
4
MAY NEED TO ADD
30 in-lbs (3.39 Nm)
2x
Page 16 of 187
5
7/16"
AN EXTENSION
Torque
= 2.5 ft-lbs
96655 Rev E
