Screen Installation
Corner Unit
Tall Screen
Short Screen
3
NOTE: Center screen on unit to yield equal
and parallel side gaps to adjacent screens.
NOTE: Do not over-tighten.
2x
5
(1)
INCLUDED PIECES:
(1)
SHORT UNIT
(2)
TALL UNIT
4
7/16"
MAY NEED TO ADD
AN EXTENSION
Torque
30 in-lbs (3.39 Nm)
2x
Page 10 of 187
Page 10 of 143
96655 Rev
96655 Rev E
