USING VIDEO FEATURES

Displaying the input source
information
You can display the format, sampling frequency, channel,
bit rate and flag data of the current input signal.
1
Set the component selector switch to AMP
and then press SET MENU on the remote
control.
The top "SET MENU" display appears in the OSD.
AMP
SOURCE
TV
SET MENU
. ;BASIC SETUP
;MANUAL SETUP
. ;SIGNAL INFO
[ ]/[ ]:Up/Down
[ENTER]:Enter
2
Press d repeatedly to select "SIGNAL INFO"
and then press ENTER.
The following information about the input source
appears in the OSD.
PRESET/CH
ENTER
A/B/C/D/E
;SIGNAL INFO
FORMAT
SAMPLING
CHANNEL
BITRATE
FLAG
[RETURN]:Exit
40
En
USING VIDEO FEATURES
SET MENU
MENU
SRCH MODE
PRESET/CH
ENTER
A/B/C/D/E
PCM
48kHz
2/0/---
---
NONE
Signal format FORMAT
Signal format display. When this unit cannot detect a
digital signal, it automatically switches to analog
input.
Display status: Analog, Digital, DolbyD, DTS, MP3,
PCM, WMA, ---
Note
"---" appears when this unit cannot detect any signals.
Sampling frequency SAMPLING
The number of samples per second taken from a
continuous signal to make a discrete signal.
Display status: 8kHz, 11kHz, 12kHz, 16kHz,
22.05kHz, 24kHz, 32kHz, 44.1kHz,
48kHz, 64kHz, 88.2kHz, 96kHz, ---
Note
"---" appears when this unit cannot detect the sampling
frequency.
Channel CHANNEL
The number of source channels in the input signal
(front/surround/LFE). For example, a multi-channel
soundtrack with 3 front channels, 2 surround
channels and LFE, is displayed as "3/2/0.1".
Note
"---" appears when there is no source channel available.
Bit rate BITRATE
The number of bits passing a given point per second.
Note
"---" appears when this unit cannot detect the bit rate.
Flag FLAG
Flag data encoded in DTS, Dolby Digital, or PCM
signals that cue this unit to automatically switch
decoders.
3
Press SET MENU on the remote control again
to exit from "SET MENU".
