FS175
Wear dust Wear ear muffs!
protection!
Important
General danger!
advice!
It is not allowed to move the machine
with rotating blade outside of the area in
which cutting
performed!
1.

Machine description

1.1

Intended use-description

The FS 175 is a floor saw with a cutting depth of up to
165 mm.
Its operating range includes the concrete and asphalt
road construction, but
longitudinal and expansion joints.
Operate the machine only using tools in accordance
with the manufacturer's instruction. Using other tools is
considered contrary to its designated use. The
manufacturer cannot be held liable for any damage
resulting from such use. The risk of such misuse lies
entirely with the user. Der FS 175 is equipped with a
petrol engine Honda GX390 and should be operated
with the fuel specified by the manufacturer.
Information: Unconditional observe
the owner's manual of the engine
manufacturer, which is added!
1.2

Technical data

Max. cutting depth
Max. blade-Ø
Flange size
Blade shaft size
Engine
Max. cutting speed with
blade
Engine shaft speed
Never touch!
Danger exists
to cut oneself!
works have to be
mainly for transverse,
165 mm - 6.5 in.
450 mm - 17.7 in.
Ø 100 mm - 3.9 in.
25,4 mm - 1 in.
Gasoline engine
HONDA GX390 8,7kW
(11,8 PS)
55 m/s
3600 rpm
Blade shaft speed
Feed
Excavation
Cutting depth control
Water supply
V-belt tension
Dimensions (L x W x H)
Weight (without water
tank and blade)
Sound power level after
DIN ISO 6393
Sound pressure level
after DIN ISO 6393
Vibration
ISO 5349 VDMA
03/2006
1.3 Shipment and provided
accessory
• Floor saw FS175 without blade
• Wrench SW 13,17, 30, 32
• Operating instruction and spare parts list floor saw
• Operating instruction engine
For the item number of accessories, please refer to the
current catalogue of GÖLZ
If accessories are used which do not correspond to
®
GÖLZ specifications, no liability is assumed for any
damage resulting hereof.
For details regarding the selection of the right GÖLZ
diamond blades, please refer to the current GÖLZ
catalogue for diamond tools.
1.4

Main parts

1.& 2. Frame
3. Cutting depth indicator
4. Poly-V belt guard
5. Blade guard
6. Engine
7. Water tank 30l
8. Hand Wheel
9. Pointer unit
10. Lifting eye
11. Push bow
- 23-
2300 rpm
manual
Manual with hand wheel
Scale on frame
30l Water tank
for dry cutting blades
manual
approx. 1200x560x1100 mm
- 47.2x22x43.3 in.
approx. 127 kg - 279.4 lbs.
No load =104 dB(A)
Full load =114 dB(A)
No load =88 dB(A)
Full load =98 dB(A)
a = 4,5 m/s²
®
