E
NGLISH
8.
Feed the cable and housing into the cable stop on the fork crown.
9.
Gently pull on the cable and align it with the groove in the rotating cam of the Motion Control damper.
10. Tighten the cable fixing bolt on the rotating cam to 8 in-lb (.9 Nm)
RockShox forks can be tuned for your particular weight, riding style and terrain.
Air Spring Tuning
W ith independently adjustable positive (top) and negative (bottom) air chambers, the
air spring system of your Reba fork can be easily tuned for your weight and riding
style. Use the following instructions as a starting point. If further fine tuning is desired,
follow the hints at the end of this section.
S
T E P
Positive air pressure determines the amount of force required to compress your fork.
More positive air pressure will result in less suspension sag and higher bottom out
forces. Less positive air pressure will result in more suspension sag and lower bottom
out forces.
Using the chart below as a guideline, inflate the positive air chamber to the desired
pressure,
N
: A
U-T
OTE
IR
URN PRESSURE SHOULD BE SET AT
Rider Weight
< 140 (63kg)
140 - 160 (63-72 kg)
160 - 180 (72-81 kg)
180 - 200 (81-90 kg)
>220 (99 kg)
S
T E P
Negative air pressure eff e c ts the amount of force required to initiate suspension travel.
Negative air pressure works with bump input AGAINST the force of the positive air
chamber. More negative air pressure results in a suspension set-up that is more active,
especially to small bump input. Less negative air pressure results in a suspension set-
up does not move or "bob" under rider input or small bumps. Using the chart below as
a guideline, inflate the negative air chamber to the desired pressure.
Rider Weight More Active
< 140 (63kg)
80-115 psi
140-160 (63-72kg) 115-130 psi
160-180 (72-81kg) 130-145 psi
180-200 (81-90 kg) 145-160 psi
>220 (99 kg)
180 psi
6
P
E R F O R M A N C E
1 - S
E L E C T I N G
Pressure Air U-Turn
80-115 psi
115-130 psi
130-145 psi
145-160 psi
180 psi
2 - S
E L E C T I N G
Air U-Turn (Pressures):
Less Active
50-70 psi
70-80 psi
80-90 psi
90-100 psi
110 psi
SRAM C
ORPORATION
T
U N I N G
P
A
O S I T I V E
IR
115
.
MM OF TRAVEL
Pressure Dual Air
70-100 psi
100-115 psi
115-130 psi
130-145 psi
160 psi
N
A
E G ATIVE
IR
Dual Air (Pressures):
More Active Less Active
70-100 psi
100-115 psi
115-130 psi
130-145 psi
160 psi
• R
U
EBA
SER
P
R E S S U R E
P
R E S S U R E
40-60 psi
60-70 psi
70-80 psi
80-90 psi
100 psi
954-308964-000, R
M
ANUAL
. B
EV
