PROGRAMMING WITH OPTIONAL DYL EXTERNAL DISPLAY
Apart from with the buttons on the control unit, the system can also be
programmed with the optional DYL external display. Some advanced fun-
ctions can only be programmed using the DYL (Fig.9-EN)
ADJUST LED BRIGHTNESS/TONDA FUNCTION
This setting enables adjustment of the led intensity during night-time
hours.
After memorising a 4-channel transmitter, the brightness of each asso-
ciated output can be adjusted as required by pressing and holding the
transmitter button. On release of the button, the light brightness will also
be memorised for subsequent activations
PH.
DESCRIPTION
Press and release the MENU button a
number of times equal to the number of the
output to be activated:
1
once for output 1,
twice for output 2,
three times for output 3,
four times for output 4
The D1 LED will flash a number of times
2
equal to the number of the output selected,
with 1 second pauses between flashes
Press and hold the button MENU for more
3
than 3 seconds
4
The led remains off
5
Release button MENU
The led emits some slow flashes.
Press the MENU button corresponding to
the required brightness
1st flash: level 1 (low brightness)
2nd flash: level 2
6
3rd flash: level 3 (factory setting)
4th flash: level 4
5th flash: level 5 (high brightness)
6th flash TONDA function:
ATTENTION in this mode you cannot adjust
light intensity
After pushing MENU botton, the led emits 4
7
quick flashes
AMBIENT LIGHT LEVEL ADJUSTMENT
This setting enables adjustment of the light sensor activation on the basis
of ambient light.
PH.
DESCRIPTION
1
Press the button MENU five times
LED D1 emits five quick flashes followed by
2
a pause
Press and hold the button MENU for more
3
than 3 seconds
4
The led remains off
5
Release button MENU
The led emits 3 slow flashes.
Press the MENU button corresponding to
the required brightness
1st flash: level 1(activation with low ambient
6
light)
2nd flash: level 2 (activation with medium
ambient light - factory setting)
3rd flash: level 3 (activation with high am-
bient light)
After pushing MENU botton, the led emits 4
7
quick flashes
PROGRAMMING THE 4 OUTPUTS (1, 2, 3 AND 4) WITH DYL
Operation of each single output with the QUADRO light sensor can be
disabled using the DYL external programmer display.
When the value is set as 1, the sensor is disabled and the output will only
be activated using the transmitter or the button connected by wire.
When the value is set as 2 (default), the output will be activated by the
QUADRO light sensor. In this case, the status of the output can be changed
using the transmitter or button, but the next day automatic control of the
output by the sensor will be restored.
TRANSMITTER PROGRAMMING
CAUTION: when BOXLED is powered, LED D2 will flash a set number of
times corresponding to the type of radio code set:
1 long flash = no radio code set
2 flashes = FIXED CODE
3 flashes = ROLLING CODE
PH.
1
2
EXAMPLE
3
+
+
+
4
5
+
+
+
N.B.
>3s
CANCELLATION OF A SINGLE TRANSMITTER
PH.
1
2
+
+
+
+
+
3
4
x4
5
N.B.
COMPLETE CANCELLATION OF RADIO CODES
EXAMPLE
PH.
x5
x5
1
>3s
2
3
4
RESET CONTROL UNIT
+
+
DEFAULT PARAMETERS
CHANNEL 1 LIGHT INTENSITY
CHANNEL 2 LIGHT INTENSITY
CHANNEL 3 LIGHT INTENSITY
CHANNEL 4 LIGHT INTENSITY
x4
OUTPUT 1 LIGHT SENSOR
OUTPUT 2 LIGHT SENSOR
OUTPUT 3 LIGHT SENSOR
OUTPUT 4 LIGHT SENSOR
AMBIENT LIGHT LEVEL
PH.
1
2
3
4
DESCRIPTION
Press and release RADIO button a number
of times equal to the number of the output to
be activated:
once for output 1,
twice for output 2,
three times for output 3,
four times for output 4
five times for output PRESET (button 1 = ou-
tput 1, button 2 = output 2, button 3 = output
3, button 4 = output 4)
The LED D2 will flash a number of times
equal to the number of the output selected,
with 1 second pauses between flashes
Press the key of the remote control to be
memorised within 10 seconds, holding it
down for at least 2 seconds
If the memorisation has been successful, the
LED D2 will give one long flash
To memorise another remote control on the
same output, repeat point 3
If no commands are given for 7 seconds,
the control board automatically quits the
programming mode
DESCRIPTION
Press the RADIO button on the receiver
until the LED lights up (about 3 seconds).
Release the key
Press the key of the remote control to be de-
leted within 10 seconds, holding it down until
the LED D2 goes out. Release the remote
control key
About 1 second after the key is released, the
LED D2 on the receiver starts to flash
Confirm the deletion by pressing the RADIO
button
If the deletion has been successful, the LED
D2 will give one long flash
If no commands are given for 7 seconds, the
control board automatically quits the deletion
mode
DESCRIPTION
Press the button RADIO and hold it down
until the LED D2 lights up (about 2 secon-
ds) and then goes out (about 2 seconds).
Release the key
About 1 second after the key is released, the
LED D2 starts to flash
To clear the entire memory, press the RA-
DIO button on the third flash
If the deletion has been successful, the LED
D2 will give one long flash
DESCRIPTION
Press the MENU button and hold it down
until the LED D1 lights up (about 3 secon-
ds) and then goes out (about 3 seconds).
Release the key
About 1 second after the key is released, the
LED D1 starts to flash
To reset and restore the factory settings,
press the MENU button on the third flash
If the deletion has been successful, the LED
D1 will give four quick flashes
EXAMPLE
+
+
+
+ 1s
+ 1s
2s
3s
EXAMPLE
(>3s) ->
->
0,5s
0,5s
3s
EXAMPLE
(>3s) ->
(>3s) ->
(+1s) +
3s
VALUES
DEFAULT
1 - 6
3
1 - 6
3
1 - 6
3
1 - 6
3
1 - 2
2
1 - 2
2
1 - 2
2
1 - 2
2
1-3
2
EXAMPLE
(>3s) ->
(>3s) ->
(1s) +
(1s) +
x4
