Specifications
N° 135 luffing jib
21,3 m basic N° 135 tubular chord luffing jib assembly consisting of 8,2
m butt, 6,1 m insert, and 7,0 m top with two 68,6 cm straight roller
bearing sheaves. Also included are RCL/RCI hardware, pin connected jib
sections, pendants, fixed strut, jib strut, backstay pendants, boom point
wheel and 26 mm luffing jib hoist line.
N° 135 luffing jib is lengthened using 3,0 m, 6,1 m and 12,2 m inserts
with wire rope pendants. Maximum luffing jib length is 51,8 m.
Lowerworks
Self-erect system includes: carbody jacking cylinders with pads, controls,
self assembly cylinder, boom-butt installation support, counterweight
cylinders and crawler handling chain.
Detachable upper boom point with one (76,2 cm) diameter tapered
roller bearing sheave for No. 74 boom top (this is same upper boom
point used on 555, 777, 999, 2250,16000 and 18000).
Blocks and hooks –
27,2 t hook block with one 76,2 cm sheave for 26 mm wire rope with
swivel hook, hook latch and swivel lock.
54 t hook block with two 76,2 cm sheaves for 26 mm wire rope with
swivel hook, hook latch and swivel lock.
91 t hook block with three 76,2 cm sheaves for 26 mm wire rope with
swivel hook, hook latch, and swivel lock.
150 t hook block with five 76,2 cm sheaves for 26 mm wire rope with
single barb swivel hook, hook latch, and swivel lock.
150 t hook block with five 76,2 cm sheaves for 26 mm wire rope with
duplex swivel hook, hook latch, and swivel lock.
Hydraulic Test Kit.
Service Interval Kits.
Special Paint Colour (other than Manitowoc standard red and black.)
Special Customer Decals: custom vinyl decal(s) of name and/or logo
from artwork supplied by customer.
Export Packaging: basic crane, boom and jib sections.
4
