To carry out this operation, proceed as follows.
1 - Remove the bottom plate (C) and the grid (D)
from the oven and clean them thoroughly.
2 - Clean the inside parts of the oven to remove
any deposits which may impair its operation.
3 - Dry the surfaces and reassemble the compo-
nents.
To carry out this operation, proceed as follows.
1 - Turn off the gas supply tap.
IT
IT
2 - Pull off the knob (A).
3 - Undo the screws (C) and remove the control
GB GB
panel (B).
4 - Undo the screw (D) of the pressure connection.
DE DE
5 - Connect the pressure gauge (E) to the pressure
test point (F).
6 - Turn the gas supply tap back on.
FR FR
7 - Light all the burners and turn the knobs to the
full flame setting (see page 10), then check that
ES
ES
the pressure reading complies with the values
provided in the table at the back of the manual.
8 - Switch off the burner, turn off the gas supply tap
and disconnect the pressure gauge.
9 - Restore the initial conditions after completing
the operation.
English
CLEANING OVEN

CHECKING GAS PRESSURE

D
C
C
A C B
- 14 -
IDM-39615201000.tif
E F
D
IDM-39614601100.tif
