CLEANING THE HOB, BURNERS AND ACCESSORIES
To carry out this operation, proceed as follows.
1 - Remove the burner cap (A) and the burner (B).
2 - Clean the burner and the flame cap thoroughly
and check that the holes in it are not blocked.
3 - Clean the ignition slot in the burner regularly.
4 - Clean the hob.
5 - After use, clean the accessories with a suitable
grease-remover product. If possible, wash in
the dishwasher.
6 - Dry the surfaces and reassemble the components.
For correct burner assembly, follow the instructions
shown in the figure.
Caution - warning
Never pour water or allow dirt to fall into the
burner as this will cause the burner to mal-
function or block the nozzle.
CLEANING OVEN
To carry out this operation, proceed as follows.
1 - Remove the bottom plate (C) and the grid (D)
from the oven and clean them thoroughly.
2 - Clean the inside parts of the oven to remove
any deposits which may impair its operation.
3 - Dry the surfaces and reassemble the compo-
nents.
CHECKING GAS PRESSURE
To carry out this operation, proceed as follows.
1 - Turn off the gas supply tap
2 - Pull off the knob (A).
3 - Undo the screws (C) and remove the control
panel (B).
4 - Undo the screw (D) of the pressure connection.
5 - Connect the pressure gauge (E) to the pressure
test point (F).
6 - Turn the gas supply tap back on.
7 - Light one of the burners, turn the knob to the full
flame setting (see page 8) then check that the
pressure reading is the same as the values pro-
vided in the table (see back of manual).
8 - Turn off the burner, disconnect the pressure
gauge and restore the initial conditions after
completing the operation.
D
C
C
A
B
C
- 11 -
A
B
IDM-39610802001.tif
IDM-39611400700.tif
E
IDM-39610802100.tif
