Fitting the suspension brackets

Please refer to pages 10 and 11 for spacing between individual components.

Fitting the toothed belt tensioner

The toothed belt tensioner is fitted at the top, between the sliding shutter suspension brackets.

Fitting the driver for Symmetric installations

The driver is fitted at the top, between the two suspension brackets for the 2
tensioner is positioned at the 1
A screw securing the front part must be removed in order to fit the toothed belt.
14 Hawa AG CH-8932 Mettmenstetten www.hawa.ch Tel. +41-1-767 91 91 Fax +41-1-767 91 78
– Frontslide 60/matic
aussen
a l'extérieur
outside
all'esterno
aussen
a l'extérieur
outside
all'esterno
st
sliding shutter, as described above.
aussen
a l'extérieur
outside
all'esterno
nd
sliding shutter. The toothed belt
Subject to modification
