H A W A
– Frontslide 60/matic

Controller types

HAWA-Control/ECO (18860) *

This controller features two built-in keys (OPEN / CLOSE), a connector for an external switch (OPEN /
CLOSE) and a link connector for switching up to 34 units in parallel (max. total length of link cable = 300 m).

HAWA-Control/PRO (18861) *

This model additionally features a 2x16-character display (e.g. for error messages), 2 sensor inputs (e.g. light
sensors) and digital inputs and outputs for connection to a bus system. The «Automatic» function activates
the built-in timer and sensors. When the random sequence generator is activated, switching times are altered
within ±1 h of the nominal set times.

General

One controller is required per drive unit. Each controller can be configured as either a master or a slave.
The controller ships with a specially designed flush-mounting box (Width x Height x Depth = 80 x 140 x 70
mm)
The supplied special connecting cable (∅ 5 mm, halogen-free) between the controller and the drive unit is
available in lengths of 5, 12 and 20 m.
The integral universal power supply requires a 100 – 240 VAC, 50 – 60 Hz input and draws a maximum
current of 0.2 A (240 VAC) to 0.4 A (100 VAC).
* see also electrical installation instructions (19705)
Subject to modification
