IC iCLPFA1 Installationsanleitung Seite 12

iCLPFA1
2
1
x4
x4
2
3/8" (9.5mm)
Wall Plate
W x4
4
V x4
9/16" (14.3mm)
12
E x4
3
INSTALL WALL PLATE TO WALL
Concrete Installation
WARNING:
Failure to provide adequate structural
strength for this component can result in serious personal
injury or damage to equipment! It is the installer's
responsibility to make sure the structure to which this
component is attached can support five times the
combined weight of all equipment. Reinforce the structure
as required before installing the component.
1. Level wall plate and mark locations of pilot holes.
2. Drill 3/8" (9.5mm) diameter holes into concrete.
3. Install anchors (E) into holes.
CAUTION:
Do not overtighten lag screws (V)!
4. Install lag screws (V) through flat washers (W), wall
plate, into anchors (E).
x4
Installation Instructions
