IC iCLPFA1 Installationsanleitung Seite 10

iCLPFA1
DIMENSIONS
MAX WIDTH 30.43" (773mm)
MAXIMUM MOUNTING PATTERN WIDTH
28.93" (735mm)
8.88
200
7.87
200
100
7.87
3.94
100
3.94 75
2.95
569
MAX WIDTH 22.41
WITHOUT UNIVERSAL INTERFACE
10
MIN 4.58 [116]
19 13
MAX 21.58 [548]
.75 .50
235
9.26
C/L OF
MOUNTING
PATTERN
445
18.50
17.50
MAXIMUM
MOUNTING
PATTERN HEIGHT
MIN 3.84 [97]
MAX 20.84 [529]
304
11.98
FLAT PANEL MOUNTING PATTERN INFORMATION
Universal: Max Width - 735 mm (28.93")
Max Height - 444 mm (17.50")
VESA: 75 x 75 mm, 100 x 100 mm,
200 x 100 mm, 200 x 200 mm,
400 x 400 mm, 600 X 400 mm
Installation Instructions
10
186
.39
7.33
