- [S1.7] Controlling algorithm
(1 - P-controller, 2 - PI-controller); (P)
- [S1.8] Pre-setted time programs - selection (- - - no selection,
1 - fixed only, 2 - user programs only,
3 - fixed and user progr.); (3)
- [S1.9] Thermostat locking (- - - no locking, 1 - no locking, but
limited function of key
3 - enabled only key Party, 4 - full lock); (2)
- [S1.10] Relay output timeout - delay (- - - none, 1 ÷ 5 min); (- - -)
1
Heating optimisation: RT2 automatically calculates the switch-on
time and at setted time (night-day changeover) the requested
temperature is already reached.
Service group S2
Service group S2 is intended for additional thermostat's service
settings. In program group S2 are the following parameters;
(Factory setting):
- [S2.1] Min. scale for temperature setting (0 °C ÷ 90 °C); (10 °C)
- [S2.2] Max. scale for temperature setting (10 °C ÷ 90 °C); (30 °C)
- [S2.3] Minimal temperature setting - limitation
(0 °C ÷ 90 °C, - - - no limitation); (- - -)
- [S2.4] Maximal temperature setting - limitation
(10 °C ÷ 90 °C, - - - no limitation); (- - -)
- [S2.5] Thermostat hysteresis (± 0.2 °C ÷ ± 10 °C); (± 0.2 °C)
- [S2.6] P-zone (± 0.5 °C ÷ ± 10 °C) (± 0.7 °C)
- [S2.7] Timer accuracy correction
(-5 sec/day ÷ 5 sec/day); (0 sec/day)
- [S2.8] Differential constant (0.1 ÷ 10)
- [S2.9] Proportional constant (0.1 ÷ 10)
- [S2.10] Integral constant (0.1 ÷ 10)
, 2 - enabled key Party and knob,
1
; (1)
1
; (1)
1
; (1)
