HOW TO USE THE CHARGER
The special purpose charger Base (Cat.#55618) has the LEDs (green, red) which indicate the status of
the charger and Battery.
Green LED
1. ○ ON
2. ● OFF
3. ○ ON
4. Blinking
5. ○ ON
6. Blinking
The following cases are considered to be the problems. Replace the charger and Battery with new ones.
● The green LED is not turned on if the power plug of the charger is plugged into a 100-240 V AC (for
household use) plug socket. (With the Battery unset)
※ Check with another electric appliance to see whether electricity is available at the plug socket.
● Neither green nor red LED is turned on or blinks if the Battery is set in the Charger.
● The green LED is not turned on 150 minutes after the red one has been turned on.
● The red LED is not turned on if the Battery is set in the charger.
Red LED Status
● OFF Power-on
○ ON Charging
● OFF Charge Completed
High temparature
Blinking
alarm
○ ON Battery alarm
Battery high
○ ON
temparature alarm
Battery Charger problems
The charger has been plugged in. (Power-on status:
Battery unset)
The Battery is being charged.
The Battery has been completed charged.
The Battery is hot. (Remove it from the Charger and
cool it down for a while before charging.)
The Battery is defective. (Replace it with a new one)
The Battery is defective and hot. (Replace it with a
new one.)
14
