EMS AIRFLOW PROPHYLAXIS MASTER Gebrauchsanweisung Seite 62

Power your device
Y Y Y Y ou can ou can now ou can ou can now now connect the power cord to the mains grid now connect the power cord to the mains grid. connect the power cord to the mains grid connect the power cord to the mains grid
Protective earth is required!
Be sure your power grid has an efficient protective earth.
Installation of the wireless pedal
The optional wireless pedal supplied with your device is already paired and ready to use (Note: A
pedal can only command one single device at a time. Pairing is maintained even if the batteries are
removed).
When you receive your new machine, all you need to do is insert the two (2) AA lithium batteries
into the wireless pedal and your device is ready to work.
In case you replace your pedal, you will need to pair it with your device. For instructions, please
read the specific Maintenance & Troubleshooting chapter.
The Bluetooth ® radio is automatically disabled (powered off) when a wired pedal connected.
The wireless pedal uses a low power, 1 dBm EIRP max, Bluetooth
unit. Interference may occur in the vicinity of this equipment.
Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be
used no closer than 30 cm (12 inches) to any part of the device, including cables. Otherwise, degradation of the
performance of this equipment could result.
ENGLISH
Insert two (2) AA 1.5V lithium batteries into the wireless pedal. Close
the cover and operate your device.
Risk of fire: use only batteries that have current limiter/short-circuit
and over-temperature protection (compliant to IEC 60086-4:2014
Safety of lithium batteries).
FB-618/EN – Rev. A-01 - 2017.03.30
Voltage: 100-240 Vac
Frequency: 50 to 60 Hz.
Operating current: 4 A max.
® 2.4 GHz radio, to communicate with the control
12/46
