7.3 Special parameter settings for DMX/DMH
Some parameters have been adapted to DMX/DMH dosing
pumps. These parameters differ from the default settings
mentioned in the supplier manual for the VFD.
Warning
When resetting the VFD to default settings, the
special parameter settings for DMX/DMH are
overwritten. The special parameters must be set
again.
7.3.1 Mandatory settings
Do not set P506 "automatic fault
acknowledgement" to 6 "always".
In case of an active error (e. g. short-circuit to
Caution
earth / short circuit), the VFD restarts
continuously and damages the system, because
P428 is set to 1 "on".
Warning
Danger of malfunction of the VFD with DMX/DMH
dosing pump. Do not change the following
settings.
Basic parameters
Code Parameter
P102 Start-up time
P105 Maximum frequency
Control terminals
Code Index Parameter
Setpoint input function
P400 -02
AIN 2 (analog input 2)
Analog ON mode
P401 -01
AIN 1 (analog input 1)
Analog ON mode
P401 -02
AIN 2 (analog input 2)
Adjustment: 0 %
P402 -01
AIN 1 (analog input 1)
Adjustment: 0 %
P402 -02
AIN 2 (analog input 2)
Adjustment: 100 %
P403 -02
AIN 2 (analog input 2)
Digital input function
P420 -01
DIN 1 (digital input 1)
Digital input function
P420 -02
DIN 2 (digital input 2)
Digital input function
P420 -03
DIN 3 (digital input 3)
P428 Automatic starting after mains OFF
* The minimum frequency for the VFD is set to approx. 5 Hz.
Extra functions
Code Parameter
P504 pulse frequency
P540 mode phase sequence
Modifications of other parameters and adaptation of the inputs
and outputs can be made with the optional "parameter box" or the
"NordCon" software. Observe the supplier manual "BU 0180" for
the VFD provided with the product.
6
Value for DMX/DMH
8 kHz
3 = CCW only; only counter-clockwise direction is possible
Subject to alterations.
Value for DMX/DMH
5 s
100 Hz
Value for DMX/DMH
01 = Setpoint frequency
2 = 0-10 V monitored
2 = 0-10 V monitored
1.36 V*
1 V
5 V
02 = Enable left (left-handed rotation)
19 = Setpoint 1 on/off
20 = Setpoint 2 on/off
1 = On (enable with level)
