Features and Controls

See Figure 2 for location.
Brake Pedal
Depressing the brake pedal applies the tractor
brake.
Cruise Control
This locks the ground speed control in forward.
The cruise control has five lock positions.
Fuel Tank
To remove the cap, turn counterclockwise.
Ground Speed Pedals
The forward ground speed pedal controls the
tractor's forward ground speed. The reverse
ground speed pedal controls the tractor's reverse
ground speed.
Headlight Switch
This turns the tractor headlights on and off.
Mower Height of Cut Adjustment
The mower cutting height adjustment lever
controls the cutting height. The cutting height can
be set to one of seven positions between 1.5" and
4.0" (3,8 and 10,2 cm).
Parking Brake
This locks the parking brake when the tractor is
stopped. See Parking Brake section.
Power Take-Off (PTO) Switch
The PTO (Power Take-Off ) switch engages and
disengages the mower blade clutch. To engage
the PTO, pull UP on the switch. Push DOWN to
disengage.
NOTE: The operator must be seated firmly in the
tractor seat for the PTO to function.
Reverse Mowing Option (RMO)
This allows the operator to mow (or use other
PTO driven attachments) while traveling in
reverse. To activate, turn the RMO key after the
PTO is engaged. The L.E.D. light will illuminate,
and the operator can then mow in reverse. Each
time the PTO is engaged, the RMO needs to be
reactivated if desired.

Ignition Switch

The ignition switch starts and stops the engine, it
has three positions:
OFF: Stops the engine and shuts off the
electrical system.
RUN: Allows the engine to run and powers
the electrical system.
START: Cranks the engine for starting.
Throttle/Choke Control (Choke-A-Matic)
The throttle/choke controls the engine speed
and choke. Move the throttle/choke control to
the FAST position to increase engine speed
and SLOW position to decrease engine speed.
Always operate at full throttle. Move the throttle/
choke control to the CHOKE position for starting
a cold engine. A warm engine may not require
choking.
Transmission Release Lever
This releases the transmission so that the tractor
can be pushed by hand.
Hourmeter (if equipped)
The hour meter measures the number of hours
the key has been in the RUN position.
