audible sound. Please check by pulling on the headrest to ensure that the headrest is fixed in
the guide slots firmly. The middle of the headrest needs to be exactly at the height of the
middle of the child's head to have the highest side protection effect. The headrest is
adjustable in 9 different positions.
1.3. Installing Heyner MultiProtect Ergo into your car
1.3.1. Conditions for installation (fig.3)
Heyner MultiProtect Ergo may be placed on all passenger seats of the vehicle that are
equipped with a three-point-vehicle-belt. The child seat must not be positioned on a vehicle
seat, which only has a lap belt, example given the centre back seat of cars with three seats in
the back.
1.3.2. Placing on the vehicle seat (fig.4)
Now put Heyner MultiProtect Ergo onto the car seat in driving direction.
1.3.3. Installation and fixing (fig.4-13)
The three-point-belt of a vehicle is made of 4 parts: the lap belt (O), the diagonal belt (N), the
belt latch (P) and the belt buckle (Q).
Fig.4-5
Make sure Heyner MultiProtect Ergo is held firmly in place, thread the belt latch (P) of your
car's three-point-vehicle-belt from the rear under harness belts (D). The lap belt part(O)
needs to be kept under the same side's fixation lugs(L).
Fig.6
Continue to guide the belt latch (P) towards the belt buckle (Q) by keeping the lap belt (O) to
3
guide over the belt guide (5 and 6) under the side's fixation lugs (L). Then guide the diagonal
belt (N) on the belt guide (4 or 7) on the bottom corner of the backrest (B). Now fasten the
three-point-vehicle-belt as you would do for an adult, with an audible »click« sound. Please
do not twist the belts during this procedure.
Fig.7-8
Release the backrest cover button (V) at the side where the diagonal belt (N) come through.
Release the backrest cover velcros (T), pull up backrest cover and move the diagonal belt
(N) under the cover. Pull down the backrest cover, press the backrest cover button(V) and
close the velcro (T). Make sure the diagonal belt (N) through the belt guide (4 or 7). Please
do not twist the belts during this procedure.
Fig.9-10
Release the booster cover velcros (U), pull up booster cover and move the lap belt (O) under
the cover. Return to close the booster cover and close velcro (U). Make sure the lap belt (O)
through the belt guide (5 and 6). Please do not twist the belts during this procedure.
Fig.11
Guide the diagonal belt (N) through the red marked belt guide hook (G) on the top of
backrest. Please do not twist the belts during this procedure.
Attention: The belts must not be twisted or blocked. The belt anchorage (K) must not be
blocked either. Please refer to the scribbles in case of any doubt or contact your dealer,
importer or manufacturer.
1.3.4. Tightening of the belt (fig.12-14)
To tighten the three-point-vehicle-belt firmly press one of your knees on the child seat.
Tighten the belt by pulling first the belt part near the belt buckle (Q)(fig.12). Then firmly pull
the diagonal belt (N) up till the child's seat is tightened to the maximum (fig.13). Finally fix
