BIOS Setup
system automatically or yiou can specify a fixed IRQ number. This is a useful function when
you want to fix the IRQ for a specific device. For example, if you want to move your hard
disk to another computer and don't want to re-install Windows
IRQ for the device installed on the new computer to fit the original computer settings.
This feature is for the operating system that will record and fix the PCI configuration status, if
you want to change it.
For the relations between the hardware layout of PIRQ (the signals from the ICH chipset),
INT# (means PCI slot IRQ signals) and devices, please refer to the table below:
PIRQ_0 Assignment
PIRQ_1 Assignment
PIRQ_2 Assignment
PIRQ_3 Assignment
PIRQ_4 Assignment
PIRQ_5 Assignment
PIRQ_6 Assignment
PIRQ_7 Assignment
Signals PCI-1 PCI-2
INT A INT D
INT B INT A
INT C INT B
INT D INT C
®
NT, then you can specify the
PCI-3 PCI-4
INT C INT B
INT D INT C
INT A INT D
INT B INT A
