6. Commissioning, operation
6.4.4.2 View
By pressing the button [Selected View] the sub menu opens on the right side. Scan or calibration view means that you see all
channels you selected on the screens. According to the numbers of selected channels the view changes a little bit. Details see
below. The graph view shows a graphic version with all selected channels.
EN
To activate the selected view press the button [Activate View] (only active if the scan is started), this action guides to the
selected scan view.
While changing from the scan application to the home application, please note that the scan is still active. This will
be seen status and information bar.
44
WIKA operating instructions, model CTR3000
