8.3
Working depth of the rotor tines
Fig. 25
Adjustment of working depth of the rotor tines is done on the lower link (1).
Bring the machine into working position on a level surface.
Lift or lower the lower link until distance "a" between front tine (2) and surface amounts to about
2 cm.
Pos: 20.21 /BA/Bedienung /Wender/Zinken/Grundeinstellg. Arbeitstiefe und Hinweis Streuwinkel @ 23\mod_1240467241911_78.docx @ 240360 @ @ 1
This setting is a default setting. The height adjustment of the tines must be adapted to the
circumstances in practice.
Note
In case the spreading angle has been shifted, the adjustment of the working depth of the rotor
tines must be checked and readjusted.
Pos: 20.22 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
KWT8828008
Operation
43
