Refit the screws and the washers in the special
holes, but do not tighten them down.
Close the ARION MAG, position the drive belt
on the guide of the front roller E and middle roller .
Unfold the ARION MAG into open position again.
Check the position of the front roller
your bicycle on the rollers and checking that the axle
for the front wheel sits directly above the front roller.
Once the front roller E is positioned, tighten the
screws (do not over-tighten as this could warp the
side members).
Close the sides with the rectangular covers . The
ARION MAG is now ready to use.
For carrying, or to save space when not using the
roller, it is advisable close the frame. Pay attention to
the position of hands when closing the roller, to avoid
squashing them between the two side members. To
close the frame, place hands at the ends of the side
members (Fig. 6).
Therefore avoid placing hands in such a way that can
become squashed between the side members (Fig. 7).
NO
5
To facilitate carrying, it is advisable to hold it by the
special grips located at the hinges (Fig. 8).
, putting
3) The rollers work best with tyre that has a smooth
tread. If using a mountain bike, to reduce noise and
increase stability change the tyre for one with a slick
tread.
For beginners, position the rollers in an entrance
hall, in a doorway or near a stable object, in order to
have a support while acquiring the necessary balance.
5) Make sure the ARION MAG rests on a flat, stable
surface.
6) The ARION MAG has 3 resistance levels: "0"
minimum resistance, "1" medium resistance, "2"
maximum resistance (Fig. 9). Select the required
EN
6
7
8
13
