Specifications; Parts & Accessories - Simplicity Regent Serie Bedienungsanleitung

ENGINE:
Briggs & Stratton
Make Briggs & Stratton®
Model Intek, 7220 Series
Displacement 44.2 cu in. (724 cc)
Electrical System Alternator : 9 amp
Battery: 12 Volt, 230 CCA
Oil Capacity 64 oz (1.9 L)
CHASSIS:
Fuel Tank Capacity Capacity: 3.5 Gallons (13,2 L)
Rear Wheels Tire Size: 22 x 10 -8
Inflation Pressure: 10 psi (0,68 bar)
Front Wheels Tire Size: 15 x 6.0-6
Inflation Pressure: 12-14 psi (0,82-0,96 bar)
Power Rating
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been
obtained and corrected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM;
horsepower values are derived at 3600 RPM. Net power values are taken with exhaust and air cleaner installed
whereas gross power values are collected without these attachments. Actual gross engine power will be higher
than net engine power and is affected by, among other things, ambient operating conditions and engine-to-engine
variability. Given the wide array of products on which engines are placed, the gas engine may not develop the rated
gross power when used in a given piece of power equipment. This difference is due to a variety of factors including, but
not limited to, the variety of engine components (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.),
application limitations, ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability.
Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this
Series engine.
Contact an authorized dealer for details.
TRANSMISSION:
K46
Type Hydrostatic Tuff Torq K46
Hydraulic Fluid 10w 30 Premium Engine Oil
Speeds Forward: 0-5.5 MPH (0-8,9 km/h)
@ 3400 rpm Reverse: 0-3.0 MPH (0-4,8 km/h)
Continuous Torque 170 ft-lbs (230,5 Nm)
Output
DIMENSIONS:
Overall Length 70.9" (180 cm)
Overall Width 48" (122 cm)
Height 44.9" (114 cm)
21

Specifications

Parts &
Accessories
