Operating the Tractor
Stopping the Tractor & Engine
1. Return the ground speed control(s) to NEUTRAL.
2. Disengage the PTO and wait for all moving parts to
stop.
3. Move the throttle/choke control to the SLOW position
and turn the ignition key to OFF. Remove the key.

Driving the Tractor

1. Sit in the seat and adjust the seat so that you can
comfortably reach all the controls and see the dashboard
display.
2. Engage the parking brake.
3. Make sure the PTO switch is disengaged.
4. Start the engine (see
5. Disengage the parking brake and release the brake
pedal.
6. Depress the forward ground speed control pedal to travel
forward. Release the pedal to stop. Note that the further
down the pedal is depressed the faster the tractor will
travel.
7. Stop the tractor by releasing the ground speed control
pedals, setting the parking brake, and stopping the
engine (see Stopping the Tractor and Engine ).

Mowing

1. Set the mower cutting height to the desired level and
set the gauge wheels to the appropriate position (if
equipped).
2. Engage the parking brake. Make sure the PTO switch
is disengaged.
3. Start the engine (see Starting the Engine).
4. Set the throttle/choke control to the FAST position.
5. Engage the PTO (Mower Deck).
6. Begin mowing.
7. When finished, shut off the PTO and raise the mower
deck.
8. Stop the engine (see Stopping the Tractor and
Engine).
WARNING
The engine will shut off if the reverse ground
speed pedal is depressed while the PTO is
on and the RMO has not been activated. The
operator should always turn the PTO off prior to
driving across on roads, paths or any area that
maybe used by other vehicles. Sudden loss of
drive could create a hazard.
WARNING
Mowing in reverse can be hazardous to
bystanders. Tragic accidents can occur if the
operator is not alert to the presence of children.
Never activate RMO if children are present.
Children are often attracted to the unit and the
mowing activity.
Starting the Engine ).

Mowing in Reverse

If an operator chooses to mow in reverse, the RMO
system can be used. To use the Reverse Mowing Option
(RMO) turn the RMO key after the PTO is engaged. The
L.E.D. light will illuminate, and the operator can then
mow in reverse. Each time the PTO is engaged the RMO
needs to be reactivated if desired. The key should be
removed to restrict access to the RMO feature.

Attachment Operation in Reverse

If an operator chooses to operate a PTO driven
attachment in reverse, the RMO system can be used. To
use the Reverse Mowing Option (RMO) turn the RMO key
after the PTO is engaged. The L.E.D. light will illuminate,
and the operator can then operate the attachment in
reverse. Each time the PTO is disengaged the RMO
needs to be reactivated if desired. The key should be
removed to restrict access to the RMO feature.

Pushing the Tractor by Hand

1. Disengage the PTO and turn the engine off.
2. Pull the transmission release (B, Figure 3) back
approximately 2-3/8" (6 cm) to lock into released
position.
3. The tractor can now be pushed by hand.
DO NOT TOW TRACTOR
Towing the unit will cause transmission
damage. • Do not use another vehicle to
push or pull this unit. • Do not actuate the
transmission release valve lever while the
engine is running.
A
Figure 3. Transmission Release Lever & Fuel Tank
14
B
