3.2.5

Encoder cable

KEB encoder cables are corresponding to the following specification:
3.2.6 Encoder line length
The maximum line length of the encoder cable is 50 m. It results from the voltage drop of the
supply line. The value is calculated as follows:
3.2.7

Tested encoders

The following encoder can be used dependent on the interface and the control:
Manufacturer Type
Heidenhain
However, this does not restrict the use of rotary encoders with same specifications of other
manufacturers.
3.3

Channel 2

The description of input X3B is depending on the used encoder interface. It is described in
a separate manual.
Signal lines
Supply lines
Particularities
Temperature range
Material number

Encoder line length =

max. encoder current I
Supply voltage U: 5.2 V
minimum input voltage U
KEB encoder cable resistance R: 0.036 Ω/m at 0.5 mm²
ERN1188
SIN/COS at Channel 1
Color
U - U
––––––––––
I
max
: see encoder description
max
: see encoder description
min
Encoder type
SIN/COS-encoder
4 x (2 x 0.14 mm²)
2 x (0.5 mm²)
trailing capable, oil resistant
constant up to 80 °C
green RAL 6018
00.S4.209-xxxx
min
• 2 • R
GB -11
