SIN/COS at Channel 1
3.2.4
Connection of the encoder
3.2.4.1
Encoder cabel at SUB-D15
• Encoder cable double-shielded and twisted in pairs
• Connect exterior shielding at both ends to PE/GND
• Connect interior shielding at one side to COM
• Do not connect exterior and interior shielding
Figure 3.3.4.1
Motor encoder plug
Name
GND
A+
A-
B+
B-
C+
C-
D+
D-
R+
R-
COM
+5.25 V
GB -10
Connection of the encoder
4
3
5
2
13
1
14
6
17
12
15
7
11
16
8
10
9
PIN
–
1
2
11
12
5
6
14
4
3
13
7
10
Socket X3A
5
4
3
2
1
10
9
8
7
6
15
14
13
12
11
PIN
Core color
–
exterior shielding
8
green
3
yellow
9
blue
4
red
6
white
1
brown
7
black
2
purple
15
gray
14
pink
13
white/green
12
gray/pink
