Scope of delivery | Technical data | Connections
Synthetic tank with rubber feet, tank mounting supports/securing brackets, lid with
vent integrated odor filter and overflow protection, FLOW 12 submersible pump
with float switch and check valve, discharge line and hose connections adapters for
washing machine and dishwasher, completely pre-assembled and wired ready for
installation.

Technical data

Article number
Free passage
Power cable
Cable length
Weight
Voltage/frequency
Type of current
Nominal current
Motor power P1
Speed
Motor protection
Plug
Protection class
Motor insulation class
Temperature-limiter
Fluid temperature

6.1 Connections

Side discharge line
Vertical inlet in tank lid
Side inlets
Washing machine connection
Vent line

5. Scope of delivery

6. Technical data
FLOWBOX
12 mm
3G 1.0
1.5 m
6.5 kg
1 x 230 V/50 Hz
Single phase
41.6 A
0.36 kW
2900 r/min
Temperature limiter built into the winding
Schuko plug
IP 68
B
120 °C
Max. 40 °C, 60 °C for 5 minutes
To the right or left, for discharge line OD = 40 mm
OD = 40 mm
1 x OD = 40 mm (right or left on top)
4 x OD = 50 mm (right and left centre and bottom)
Nozzle for mounting on free intake OD = 40 mm
Connection of separate vent line OD = 50 mm
possible on one of the two centre, side outlets
