Nidec Commander C200 Schritt-Für-Schritt-Anleitung Seite 4

A Drill template for wall mounting is included on the drive packaging (shown below).
Alternativly refer to the table below for the mounting and overall dimensions.
Frame
H
Mounting
143 mm
1
(5.7 in)
194 mm
2
(7.63 in)
215 mm
3
(8.46 in)
265 mm
4
(10.43 in)
4
+
+
W
Overall Mounting
160 mm 53 mm
(6.3 in) (2.08 in)
205 mm 55 mm
(8.07 in) (2.17 in)
226 mm 70.7 mm
(8.9 in) (2.80 in)
277 mm 86 mm
(10.9 in) (3.40 in)
+
+
D
Overall Overall
75 mm 130 mm
(2.95 in) (5.1 in)
75 mm 150 mm
(2.95 in) (5.9 in)
90 mm 160 mm
(3.54 in) (6.3 in)
115 mm 175 mm
(4.5 in) (6.9 in)
Ø
Diameter
5 mm
(0.2 in)
5 mm
(0.2 in)
5 mm
(0.2 in)
6 mm
(0.23 in)
C200/C300 Step By Step Guide
Issue Number: 1
Weight
0.75 kg
(1.65 Ib)
1.3 kg
(3.0 Ib)
1.5 kg
(3.3 Ib)
3.13 kg
(6.9 Ib)
