19 Sectional drawing

Protective caps for
sealing bolts on
actuator valve body
Optical
position indicator
Actuator
Closing spring
for control function 1
(normally closed (NC))
Connector 4
Control medium
Allen screws
connector for control
function 2 (normally
Anti-twist system
open (NO)) / vent hole
for control function 1
Piston
(normally closed (NC))
Pre-tension spring
Piston gasket
Leak detection hole
Piston guidance
Diaphragm tappet
Union nut
Valve body connection Valve body
Variable mounting lug
C50 HPW
