DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The CL-48 LED-CLUSTER has 3 DMX-modes. Set DIP-switches 11 and
12 according to the table below.
Table 4:
DMX-channels DIP
per LED bar 11
15 OFF
12 ON
6 OFF
Control-channel - Internal programs
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 40 0B 28 4% 16%
41 70 29 46 16% 27%
71 100 47 64 28% 39%
101 130 65 82 40% 51%
131 160 83 A0 51% 63%
161 190 A1 BE 63% 75%
191 220 BF DC 75% 86%
221 255 DD FF 87% 100%
Control-channel - Strobe
Decimal Hexad. Percentage S/F
0 0 00 00 0% 0%
1 95 01 5F 0% 37%
96 127 60 7F 38% 50%
128 159 80 9F 50% 62%
160 191 A0 BF 63% 75%
192 223 C0 DF 75% 87%
224 255 E0 FF 88% 100%
Control-channel - Dimmer intensity
Only available, if control channel Internal Programs is not active.
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel – Speed
Only available, if control channel Internal Programs is active.
Decimal Hexad. Percentage S/F
0 255 0 FF 0% 100%
DIP
DMX-mode
12
Individual LED control,
OFF Internal programs, Strobe,
Dimmer/Speed
OFF Individual LED control
ON R, G, B control per group
S No function
S Internal program 1
S Internal program 2
S Internal program 3
S Internal program 4
S Internal program 5
S Internal program 6
S Internal program 7
S Internal program 8
S Open
F Strobe-effect with increasing speed
S Open
F Pulse-effect in sequences
S Open
F Random strobe-effect with increasing speed
S Open
F Gradual adjustment of the dimmer intensity from 0 to 100 %
F Speed adjustment min to max
LED
Control
1~12
1~12
1~3
Feature
Feature
Feature
Feature
26/55
Internal
Strobe
Programs
13 14
4 5
