Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.

OPERATION

Connect the effect to the mains and switch it on via the POWER-switch.

Stand Alone-operation

In the Stand Alone mode, the CL-48 LED-CLUSTER can be used without controller. You can do without a
controller as the features a built-in microphone, which provides automatic sound control.
Disconnect the FUTURELIGHT CL-48 LED-CLUSTER from the controller and set DIP-switch 10 to ON and
DIP-switch 11 to OFF to select Stand Alone sound control mode.

Master/Slave-operation

The master/slave-operation enables that several bars/devices can be synchronized and controlled by one
master-device.
Choose the bar which is to control the effects. This bar then works as master-device and controls all other
slave-devices, which are to be connected to the master-device via a balanced microphone lead. Connect the
DMX OUT-jack with the DMX IN-plug of the next device.
Set the DIP-switch, as listed in table 1, for the master-device. When the unit is running in Master/Slave
mode, all slave-devices must be set to DMX address 001, and DIP-switches 11 and 12 have to be set to
OFF.
International
L
N
