The maximum ambient temperature T = 45° C must never be exceeded.
a
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.

DESCRIPTION OF THE DEVICE

Features

Professional LED colour-changer
• Cluster with 4 bars - each with 12 LEDs
• Equipped with 48 x 1 W LEDs: 16 x red, 16 x blue, 16 x green
• 6, 12 or 15 DMX channels selectable for each bar
• High power LEDs made by Lumileds, USA
• 100 000 hours LED life
• Each LED can be controlled individually
• Switch-mode power supply
• Automatic power supply adaption between 90 and 260 Volts without power selector
• Stepless RGB colour changing
• Adjustable color-change speed and strobe effect
• DMX-controlled operation or stand alone operation with Master/Slave-function
• Strobe-effect with 1-18 flashes per second
• Programmed chaser
• 8 built-in programs can be called up via DMX-controller or dip switches
• Sound-controlled via built-in microphone
• Rainbow-effect with adjustable speed
• Dip switches for adjusting the DMX-starting address and stand alone programs
• Advantages of LED-technology: extremely long life, low power consumption, minimal heat emission,
defacto maintenance free with brilliant light radiation
• DMX-control via every standard DMX-controller
