As the suction depth increases, the performance of the electro-
pump decreases.

1.4 Technical characteristics

Topic Parameter
Voltage
ELECTRIC
POWER SUPPLY Frequency
Maximum power
Overall dimensions
STRUCTURAL
Empty weight
CHARACTERI-
(excluding packaging)
STICS
Protection class
Insulation class of the
motor
Maximum head
Maximum flow rate
HYDRAULIC
Priming
PERFORMANCE
Maximum working
pressure
Max liquid temperature
WORKING Max environment
CONDITIONS temperature
Environment temperatu-
re of storage
e.sybox mini
1 ~ 110-127 1 ~ 220-240
VAC VAC
50/60 Hz
2- INSTALLATION
800 W
445x262x242 mm without
feet support
13,6 kg
IP x4
F
55 m
80 l/min
<5min at 8m
7.5 bar
40 °C
50 °C
-10÷60 °C
Constant pressure
Protection against dry running
Antifreeze protection
FUNCTIONALITY
AND Anticycling protection
PROTECTIONS
Motor overload protection
Protection against abnormal supply voltages
Protection against excess temperature
The system is designed for indoor use: do not install the system
outdoors and/or directly exposed to atmospheric agents.
The system is designed to be able to work in environments
where the temperature remains between 0°C and 50°C (on con-
dition that the electric power supply is ensured: see par. 5.6.8
"anti-freeze function").
The system is suitable for treating drinking water..
The system cannot be used to pump salt water, sewage, inflam-
mable, corrosive or explosive liquids (e.g. petroleum, petrol, thin-
ners), greases, oils or food productsi.
The system can suck up water with a level that does not exceed
the depth of 8 m (he height between the water level and the
pump suction mouth).
If the system is used for the domestic water supply, respect the
local regulations of the authorities responsible for the manage-
ment of water resources.
When choosing the installation site, check that:
• The voltage and frequency on the pump's technical data plate
correspond to the values of the power supply system.
