4.3.3) RDC level programming through the transmitter
The procedure allows the setting of the impact force which the motor will apply in the box closure phase (4 adjustable thresholds).
Table "A8" RDC level programming
Press the ▲ and ■ keys of the transmitter memorised in mode I at the same time
1.
until the motor makes 1 beep
2. Within 5 seconds, with a frequency of 2 seconds, the raising button of the transmitter
to select the desired level:
- pressed once = level 1 (standard(*) reduction of the motor torque)
- pressed twice = level 2 (greater reduction of the motor torque)
- pressed 3 times = level 3 (much greater reduction of the motor torque)
- pressed 4 times = level 4 (high reduction of the motor torque)
3. Wait for the motor to confirm the level just selected with a number beeps
(example: 3 beeps = level 3 selected)
Within 5 seconds from the last beep, confirm the level by briefly pressing the ■ key
4.
5. If the procedure has been carried out correctly the motor will make 3 beeps
4.3.4) Activation of the Closure torque reduction (RDC)
The torque reduction is a programmable function that prevents excessive tension on the fabric by reducing the pulling torque by approxi-
mately 50% just before the awning is fully retracted against the box.
Table "A9" Programming the torque reduction (RDC)
Press and hold down button ■ of a previously memorized transmitter until you hear a
1.
beep (after about 5 seconds)
Release and press again button ■ for another 5 seconds until 4 rapid beeps are heard
2.
Press button ■ until 3 beeps indicate that the RDC function has been activated
3.
4.3.5) Programming of the "FRT" function
After having programmed positions "0" and "1", position "2" can be programmed that activates the retraction function FRT of the fabric.
Follow the indications in table "A10" to program position "2".
Table "A10" Programming position "2"
Press and hold down button ■ of a previously memorized transmitter until you hear a
1.
beep (after about 5 seconds)
Press and hold buttons ■ ▼ for another 5 seconds until 2 rapid beeps are heard.
2.
At this point the awning automatically moves to the position of the lower limit switch
(position "1")
Use buttons ▼ and ▲ within 5 seconds to position the awning in the desired
3.
retraction position
Confirm the position with button ■ of the transmitter within 5 seconds until 3 beeps are
4.
heard. Afterwards the awning will move to the lower programmed limit switch position
(position "1")
Note: if the programming described in point 4 is not confirmed the modifications are aborted and the previous programming is maintained.
If after having programmed this function you wish to eliminate it, the procedure in table A13 must be followed, omitting step 3 which would
modify position "1".
When position "2" is programmed, the electronic control unit automatically calculates the difference between positions "2" and "1", so that
each time a lower command is given, the awning lowers to the greater of the two positions and then retrieves the fabric until arriving to the
lesser of the two positions.
EN
Example
x1 = level 1
x2 = level 2
x3 = level 3
x4 = level 4
5s
Example
5s
5s
Example
5s
5s
