6.2.3) Example of Mode I and Mode II combined memorization

Group commands can be created taking opportune advantage of the Mode I and Mode II memorizations as shown in the diagram.
• The T1 transmitter (Ergo1) memorized in Mode I on A1 and A2
simultaneously commands the Up, Stop or Down of both A1 and
A2.
• The T2 transmitter (Plano1) memorized in Mode I on A3 only, com-
mands the Up, Stop or Down of A3 only.
• The T3 transmitter (Planotime) memorized in Mode 1 on A4 only,
commands the Up, Stop or Down of A4 only.
• The T4 transmitter (WM001C) memorized in Mode II (Step-by-
Step) commands A4 only.
• The T5 transmitter (WM003G) memorized in Mode I to command
A1 and A2 with group 1, A3 with group 2 and A4 with group 3;
commands the Up, Stop or Down of A1 and A2, A3 or A4.
• The T6 transmitter (Flo4R) memorized in Mode II on A4 (buttons 1
and 3) on A5 (button 2) and on A6 (button 4), commands the Up
and Down of A4, or the opening of the garage door A5 or the
opening of the automatic gate A6.
WARNING:
• Some functions (positions, operations...) cannot be programmed with the transmitter memorized in Mode II as different buttons need to
be pushed in this phase, such as button ■ and button ▲ for example.
• The "multiple group" commands cannot be used with a transmitter memorized in Mode II.
When one or more transmitters have already been memorized, others may be memorized in Mode II as shown in table A16.
Table "A16"
Memorizing additional transmitters in Mode II
1.
Press and hold down the button to be memorized of the new transmitter
(for approx. 5 seconds) until you hear a beep; then release it
2.
EWithin 5 seconds push and hold the button of an old and already memorized
transmitter (approx. 5 seconds) until 2 beeps are heard; then release the button
3.
Within 5 seconds start to push the same button of the old transmitter the same number
of times equal to the required command: 1="Step-by-Step" 2="Up" 3="Down" 4="Stop"
4.
After about 3 seconds the same number of beeps as the selected command are heard.
5.
Within 2 seconds push the same button of the new transmitter
6.
Release the button when you hear the first of the 3 beeps confirming memorization
If at point 5 the same number of beeps equal to the selected command are not heard, simply do not push any more buttons and wait a few
seconds for the programming to finish without memorizing.
Note: If the memory is full (14 transmitters), 6 beeps will indicate that the transmitter cannot be memorized.
A new transmitter can easily be memorized with the same characteristics as that of the old one by following the procedure in table A17.
The "new" transmitter will inherit the characteristics of the old one, i.e. if the old transmitter was memorized in Mode 1, the new one will also
function in Mode 1, if the old transmitter was memorized in Mode II then the button of the new transmitter will be associated to the same
command as that of the old one.
Table "A17"
Memorizing other transmitters
1.
Press and hold down the button to be memorized of the new transmitter
(for approx. 3 seconds) then release it
2.
Press and hold down the button to be memorized of the old transmitter
(for approx. 3 seconds) then release it
3.
Press and hold down the button to be memorized of the new transmitter
(for approx. 3 seconds) then release it
4.
Press and hold down the button to be memorized of the old transmitter
(for approx. 3 seconds) then release it
5.
The memorization of the new transmitter is confirmed with 3 beeps
Note: If the memory is full (14 transmitters), 6 beeps will indicate that the transmitter cannot be memorized.
Example
New
5s
Old
5s
New
1-4
3s
1-4
New
Example
New
>3s
Old
>3s
New
>3s
Old
>3s
EN
10
