8.1

Materials

Component
Housing
Pump head
Diaphragm
Valve body
Valve balls
Sealings
Wetted parts
Colour
8.2

Equipment marking / Type plate

Fig. 12: Type plate TurboSMART II
1 Barcode with order number
2 Protection class marking IP52
3 CE-marking
4 Barcode with production code of the year
5 Manufacturer's address
6 Annual production code
7 Quantity of the pump
Pump version EPDM
Cover: ABS, back cover: PPE (Noryl)
EPDM
PP (or PVDF) / EPDM (bzw. FKM) / Ceramic
Cover: Ecolab grey, back cover: black
8
9
10 Voltage specification [V]
11
12 Order number
13 Typ
14 Device designation
39
Pump version FKM
PP (or PVDF)
EPDM / PA PTFE / Ms
PP (or PVDF)
Ceramic
Current data [A]
Noise level [(dB) A]
Materials of the pumpe
Technical Data
FKM
