Functional description

The Turbo SMART II dosing pumps are electrically motor-driven diaphragm dosing
pumps, suitable for use with non-contaminated, non-abrasive dispensing media, viscosity
of max. 1100 mPas.
NOTICE!
Only Ecolab products approved for this dosing system may be used.
No liability is accepted for the use of products other than those
approved!
An integrated stepper motor drives the pump.
The stepper motor is controlled by integrated electronics, which control the dosage
amount by means of variable rotational speed. Various dosage profiles and modes of
operation (intake and dosage stroke speeds) can be configured.
The Turbo SMART II is available in different versions:
Article no. Pump head
106052
106053
106099
106064
106065
106098
106074
106096
106097
DANGER!
Danger of the pump starting automatically
The pump is controlled via the power supply.
The automatic start of the pump is started as soon as the power supply is
connected, without having to press a switch/button beforehand.
For safe handling of the pump, a safety switch must be connected on site
or connected via the emergency stop function of the higher-level control
unit.
Sealings
EPDM
PP
FKM
PVDF
EPDM
Functional description
Scope of delivery
EU, complete pump with accessories
- packaged
EU, pump
- unpacked
US, pump module
- packaged
EU, complete pump with accessories
- packaged
EU, pump
- unpacked
US, pump module
- packaged
EU, complete pump with accessories
- packaged
US, pump module
- packaged
US, pump module
- packaged
21
Suitable for
Alkaline products
Acid products
Products
containing
peracetic acid
Chlorinated
products
