2.6.2 Key operation / LED display

The two keys can be used to perform the following functions:
Key symbol Functions

2.6.2.1 Status display

2.6.2.2 Standard Menu

press once : go up one menu item, increase number by one
press twice in rapid succession : increase number by ten
press once : go down one menu item, decrease number by one
press twice in rapid succession : decrease number by ten
press and hold right key, then press left key as well :
enter a number, return function name
S700 Safety Guide | 2 English
Kollmorgen | September 2015 67
