DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
Addressing
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED TBL-200 barrel effect COB will respond to the controller.
If you set, for example, the address to channel 8, the device will use the channel 8 to 14 for control.
Please, be sure that you don't have any overlapping channels in order to control each LED TBL-200 barrel
effect COB correctly and independently from any other fixture on the DMX data link.
If two, three or more LED TBL-200 barrel effect COB are addressed similarly, they will work similarly.
For address setting, press the Mode-button until the display shows „A.001" and set the desired address via
the Up/Down-buttons.
Controlling:
After having addressed all LED TBL-200 barrel effect COB, you may now start operating these via your
lighting controller.
Note:
After switching on, the LED TBL-200 barrel effect COB will automatically detect whether DMX 512 data is
received or not. If the data is received, the display will show "A.001" with the actually set address. If there is
no data received at the DMX-input, the display will show "A001".
This situation can occur if:
- the 3 Pin XLR plug (cable with DMX signal from controller) is not connected with the input of the LED TBL-
200 barrel effect COB.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.

DMX-protocol

Control-channel 1 - Horizontal mirrored cylinder movement (PAN)
Push slider up in order to move the mirrored cylinder.
Gradual mirrored cylinder adjustment from one end of the slider to the other (0-255, 128-center).
The mirrored cylinder can be stopped at any position you wish.
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 2 - Mirrored cylinder rotation
Push slider up to rotate the mirrored cylinder.
Decimal Hexad. Percentage
0 7 00 07 0% 3%
8 127 08 7F 3% 50%
128 128 80 80 50% 50%
129 255 81 FF 51% 100%
Control-channel 3 - Color-wheel
Linear color change following the movement of the slider.
In this way you can stop the color-wheel in any position.
Decimal Hexad. Percentage
0 15 00 0F 0% 6%
16 31 10 1F 6% 12%
32 47 20 2F 13% 18%
S/F Feature
F Gradual adjustment of the mirrored cylinder position from left to right
S/F Feature
S No rotation
F Forwards rotation with increasing speed
S No rotation
F Backwards rotation with increasing speed
S/F Feature
S Open / white
S Dark blue
S Orange
