ELECTRICAL DIAGRAM WITH THREEPHASE SENSING
12 WIRES ELECTRICAL DIAGRAM WITH THREEPHASE SENSING
N o t e :
Th e p a r a l l e l d e vi c e P D i s o p t i o n a l u p t o 3 5 0 k V A .
Th e l i n k P a c t i va t e s o r d e a c t i va t e s t h e p a r a l l e l d e vi c e , i f i t i s
p r e s e n t .
