5

Terminals

5.1

Power terminal connections

Figure 5.1 Commander SE Size 1 power terminal connections
Thermal
protection
Figure 5.2 Commander SE Size 2 to 4 power terminal connections
When a Commander SE Size 2 200V unit is used on single phase, use terminals L1
NOTE
and L2.
40
L1
Optional
RFI filter
Optional
line reactor
Fuses
Circuit breaker
/Isolator
L1
Mains
Supply
+ -
DBR
Braking
Resistor
device
Stop
Start/
Reset
Optional
Drive Size
1 & 2
3 & 4
5
www.controltechniques.com
L2/N PE U V
*
Motor
L2/N
Supply
* See Fuses on page 29
Ground
L1 L2 L3 PE
Optional RFI
filter
Optional
line reactor
Fuses
L1 L2 L3
Mains Supply
Supply Ground
Maximum Power Terminal Screw Torque
1Nm (9lb in)
2Nm (18lb in)
15Nm (11lb ft)
W
Motor
Ground
Optional
Motor
Ground
U V W
Motor
Ground
Optional
Motor
Motor
Ground
