Novoferm NovoSpeed Retail Montageanleitung Seite 7

4.5
GB
Align the column vertically and clamp it to the wall with clamps.
Note! Use fillings to protect the column.
4.6
Position the second column; align this too vertically and clamp it to the wall with
clamps. Again, use fillings to protect the column.
10
4.7
Make sure that the columns are in the middle in relation to the clear width. Next attach
the columns to the wall structure with bolts as indicated.
4.8
Use the supplied M8 bolts to attach the columns and the consoles to the wall structure
using the appropriate holes and recesses.
GB
11
