The type of soil and working conditions will deter-
mine the actual setting of the tilling depth. In some
soils, the desired depth is reached by fi rst passing
over garden. In other soils, the desired depth is ob-
tained by going over the garden two or three times.
In later case, the depth regulator rod should be low-
ered before each succeeding pass over the garden.
Passes should be made across the length and width
of the garden alternately. Do not try to dig too deeply
in the fi rst pass. If the machine jumps or bucks, allow
the unit to move forward at a lightly faster rate.
If the tiller stops forward motion and tries to dig in
one spot, rock the handles from side to side to start
it moving forward again.
Rocks which are turned up should be removed from
the garden area.
10.3 Cultivating
Cultivating is loosening or digging around growing
plants to disrupt weeds and aerate soil. Less than 50
mm depth is always desirable.

11. Maintenance

Keeping your tiller in top running condition will pro-
long its life, and help you obtain optimum perfor-
mance whenever you wish to till your garden.
Cleaning Tine Area
Clean the tiller underside of the tine shield after each
use. The dirt washes off tines easier if rinsed off im-
mediately instead of after it dries.
1. Turn off engine. Engine must be cool.
2. Keep the engine's throttle control in its "
tion, and remove spark plug wire from spark plug
and secure.
D E / A T / C H M F D E / A T / C H
3. Remove all vegetation, string, wire, and other
materials that may have accumulated to the axle
between the inside set of tines and the seal on the
transmission housing.
Checking the clutch
- Clutch: as clutch wears out, the same lever
could have a wider opening, being so uneasy to
use. This means that it is necessary to adjust
the cable, setting clutch lever on its original
position acting on the adjustment device and on
counternut.
4. Always towel dry the tiller afterwards and apply
a light coat of oil or silicone to prevent rusting or
water damage.
5. Replace spark plug wire.
m ATTENTION! Never use a "pressure washer"
to clean your tiller. Water can penetrate tight
areas of the tiller and its transmission case and
cause damage to spindles, gears, bearings, or
the engine. The use of pressure washers will re-
sult in shortened life and reduce serviceability.
Lubrication
Remove the tine assemblies to lubricate the tine
shafts at least once a season.
Use portable tool lithium grease.
Do not overfi ll. Too much grease can create
pressure which could damage seals.
Engine Maintenance
Follow the instructions in the engine manual!

12. Storage

If the tiller will not be used for a period longer than
30 days, follow the steps below to prepare your tiller
for storage.
1. Drain the fuel tank completely. Stored fuel contain-
ing ethanol or MTBE can start to go stale in 30
days. Stale fuel has a high plastic content and can
clog the carburetor and restrict fuel fl ow.
2. Start the engine and allow it to run until it stops.
This ensures no fuel is left in the carburetor. Run
the engine until it stops. This helps prevent plastic
deposits from forming inside the carburetor and
possible engine damage.
3. While the engine is still warm, drain the oil from
the engine. Refi ll with fresh oil of the grade recom-
mended in the Engine Manual.
4. Allow the engine to cool. Remove the spark plug
and put 30 ml of high quality motor oil into the
cylinder. Pull the starter rope slowly to distribute
the oil. Replace the spark plug.
m ATTENTION! Remove the spark plug and drain
all of the oil from the cylinder before attempting to
start the unit after storage.
5. Use clean cloths to clean off the outside of the
tiller and to keep the air vents free of obstructions.
m ATTENTION! Do not use strong detergents or pe-
" posi-
troleum based cleaners when cleaning plastic parts.
Chemicals can damage plastics.
6. Inspect for any loose or damaged parts. Repair or
replace damaged parts and tighten loose screws,
nuts or bolts.
7. Remove the tines. Clean and apply oil to the tines
and tine shafts to prevent rusting. Mount the tines
onto the tine shafts.
8. Coat the wheel axles lightly with oil. Oil the throttle
cables and all visible moving parts. Do not remove
the engine cover.
9. To store with the handles folded down, loosen
the knobs that secure the upper handle to the
lower handles. Carefully fold the upper handle
down. Do not allow control cables to become
pinched or bent. Tighten the knobs.
10. Store your tiller in upright position in a clean, dry
building that has good ventilation.
m ATTENTION! Do not store tiller with fuel in an
non-ventilated area where fuel fumes may reach
fl ame, sparks, pilot lights or any ignition sources.
Use only approved fuel containers.
