8 Circuplodes

Three different types of electrodes are available for the Curapuls 670.
With the Circuplode diam. 140 mm a high in-depth radiation in small regions can be achieved. It is the
most universal and therefore the most used emitter.
The Circuplode diam. 90 mm is perfectly suited for treatment of small joints (e.g. the wrist joint) and in
children's physiotherapy.
The Circuplode-E (ellipse-shaped Circuplode) is especially for treatment of larger parts of the body, such
as the hip joint and large oblong muscles.
The Circuplode-E can generate a frequency of 800 Hz. Ideal for thermal treatment.
With most pre-programmed treatment protocols an advice is given regarding the best suited Circuplode
for the selected pathology.
With these electrodes a towel should be placed between the skin and the electrode, after clearing the
area to be treated.

9 Operation

In the Curapuls 670, pulse duration, pulse frequency, power and treatment duration are adjustable. When
two electrodes are used, the selected pulse frequency and treatment duration apply to both electrodes,
while the other parameters can be set separately for each electrode.
Connect the necessary electrodes and switch the equipment on by means of the on/of switch. After
switching on and performing the self test of the Curapuls 670, the information screen appears stating the
software and language version.
After a few seconds the main menu appears with the following possibilities:
•
Set parameters
•
Treatment memory
•
Treatment protocols
9.1

System settings

If you are in the main menu, you can set the standard settings of the Curapuls. To do so, keep the "arrow
left" key pressed for 2 seconds. The sub screen appears with the following possibilities:
Language
By turning the central control you can choose the desired language.
By pressing the "arrow down" key, you go to the next option.
Contrast
By turning the central control you can choose the desired contrast.
Sound
You can choose between "on" and "off" by turning the central control. If you choose "on", you will be
hearing a beep tone every time you press an "arrow" key, the Enter key or the Start key.
Mode
Here you can choose between a conventional screen and a screen only indicating the mean power.
Screen
You can choose between "normal", i.e. dark letters on a light background or "inverse" (light letters on a
dark background).
After you have set your preferences, use the "arrow down" key to return to the main menu. Press the
Enter key.
