Contents
GB
1
Operating Elements and Connections . . . . 12
2
Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . 12
3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 13
4
Selecting and Mounting the Lens . . . . . . . . 13
5
Mounting the Camera . . . . . . . . . . . . . . . . . 13
6
Connecting the Camera . . . . . . . . . . . . . . . . 13
7
Setting into Operation . . . . . . . . . . . . . . . . . 14
7.1 Main menu 1 . . . . . . . . . . . . . . . . . . . . . . . . . 14
lines D/N MODE to ALC/ELC . . . . . . . . . . 14
7.1.2 Submenu ALC/ELC . . . . . . . . . . . . . . . . . . 14
lines SHUTTER to NEXT . . . . . . . . . . . . . . 15
7.2 Main menu 2 . . . . . . . . . . . . . . . . . . . . . . . . . 16
lines GAMMA to PRIVACY ZONE . . . . . . . 16
7.2.2 Submenu PRIVACY ZONE . . . . . . . . . . . . . 17
7.2.3 Submenu ID . . . . . . . . . . . . . . . . . . . . . . . . 17
lines BLEMISH to BACK . . . . . . . . . . . . . . . 17
7.3 Menu for the RS-485 interface . . . . . . . . . . . . 18
8
Specifications . . . . . . . . . . . . . . . . . . . . . . . .18
12
1 Operating Elements and Connections
(see page 2)
1 Selector switch for adjusting the camera to the lens
type used
VIDEO = for video signal controlled lens
DC = for DC controlled lens
2 Buttons
and
for selecting a menu item
3 Buttons
and
for selecting a menu line
4 Button Enter for activating a menu item and for
changing an adjustment
5 Jack RJ-45 of the interface RS-485 for remote con-
trol of the menu adjustments
6 Mains cable for connection to the power supply
(90 - 260 V~/50 Hz)
7 Adapter with two threaded jacks [thread 6.3 mm
1
(
/
")] for camera mounting; the adapter can be
4
screwed to the upper side or lower side of the
camera
8 POWER LED
9 BNC jack for the video output, 1 Vpp at 75 Ω
10 Jack for connection of a lens with automatic iris
control [AI lens ("auto iris")]; for the pin configura -
tion of the jack see chapter 4
11 Adjusting wheel for presetting the focus
(adapta tion to the lens)
2 Safety Notes
The unit corresponds to all required directives of the
EU and is therefore marked with
WARNING The camera is supplied with hazardous
mains voltage. Leave servicing to skilled
personnel only. Inexpert handling of the
unit may cause an electric shock
hazard.
It is essential to observe the following items:
G
The camera is suitable for indoor use only. In case of
outside mounting it must be placed into a weather-
proof housing.
G
Protect the camera against dripping water and
splash water, high air humidity, and extreme temper -
atures (admissible ambient temperature range
-10 °C to +50 °C).
G
Do not set the camera into operation and immediate-
ly disconnect the mains plug from the mains socket if
1. there is visible damage to the unit or to the mains
cable,
2. a defect might have occurred after a drop or simi-
lar accident,
3. malfunctions occur.
The camera must in any case be repaired by skilled
personnel.
G
A damaged mains cable must only be replaced by
the manufacturer or by authorized, skilled personnel.
G
Never pull the mains cable to disconnect the mains
plug from the mains socket, always seize the plug.
G
For cleaning only use a dry, soft cloth, by no means
chemicals or water.
G
No guarantee claims for the camera and no liability
for any resulting personal damage or material dam -
.
