7) LEVEL level of the iris control
The iris can always further be opened or closed
with the buttons and
ness can be changed:
-•------- The iris is further closed.
-------•- The iris is further opened.
Note: If the wide dynamic function is switched on in
the menu line WD, the level adjustment of the iris
control only has a minor effect on the picture
brightness.
Select the next menu line with the button
8) EXIT Go from this menu item back to the main
menu 1: Press the button Enter.
7.1.3 Main menu 1, lines SHUTTER to NEXT
1) With the button
which the adjustment is to be changed.
2) SHUTTER electronic shutter
Press the button Enter so many times until the
desired adjustment is displayed:
OFF The automatic electronic shutter is
switched off, i. e. the shutter time is
the system.
AUTO The camera automatically adjusts the
shutter time according to the lighting conditions.
1/50 ... 1/120k Fixed shutter time between
1 / s and 1 /
50 120 000
objects in focus, a short exposure time may be
necessary.
Note: The individual shutter functions are only
available for certain adjustments in the submenu
ALC/ELC (chapter 7.1.2):
Menu adjustments
ELC/ALC WD
ELC WD - - -
ALC WD OFF
ALC WD ON
After the adjustment has been made, select the
next menu line with the button
3) SENS UP longer exposure time at poor lighting
conditions
Press the button Enter so many times until the
desired adjustment is displayed:
OFF no longer exposure time
AUTO:X2 ... X320 The camera automatically
adjusts a longer exposure time at poor lighting
conditions. With the adjustment AUTO:X2, this
can be 1 / s as a maximum and with the
25
adjustment AUTO:X320, 6.4 s as a maximum.
Note: The function AUTO is only available with
certain adjustments of ALC/ELC and SHUTTER:
Menu adjustments Menüeinstellun-
ELC/ALC SHUTTER
ALC OFF
ALC 1/120 ... 1/120K
ELC AUTO
ELC 1/50 ... 1/120K
. Thus, the picture bright -
or select the menu line in
1 / s due to
50
s: For reproducing moved
Possible shutter functions
OFF AUTO 1/50 ... 1/120K
— X
X —
— — —
.
Possible SENS UP functions
OFF AUTO
X X
X —
X X
X —
After the adjustment has been made, select the
next menu line with the button
4) GAIN Control range of the AGC (automatic gain
control)
Select the adjustment with the button Enter:
TURBO control range 0 – 30 dB: Required at
very poor illumination, however, a stronger
picture noise will occur.
OFF The AGC is switched off. Only use this
adjustment if the surveillance range is always
.
illuminated in an optimum way.
NORMAL control range 0 – 24 dB
After the adjustment has been made, select the
next menu line with the button
5) SNYC synchronization
Press the button Enter so many times until the
required adjustment is displayed:
INT The camera is synchronized internally.
This is the default setting if only the picture of
this camera is viewed on the connected moni-
tor. Go to the next menu line with the button
LL:000 The camera is synchronized by the
mains voltage (line lock). Thus, the picture sig-
nals of several cameras can be synchronized
so that a disturbing picture rolling on the moni-
tor is prevented when switching between diffe-
r ent camera signals. If required, the phase be t-
ween the mains voltage and the synchroniza -
tion may be displaced between 0° and 300°:
a) After selecting the adjustment LL:000,
"LL" flashes. Select the first zero with the
button
b) Coarsely adjust the phase in steps of hun-
dreds with the button
c) Repeat the procedure for the tens digit and
X
units digit for fine adjustment.
X d) Go to the next menu line with the button
6) BLC backlight compensation
It serves to brighten up objects in the backlight.
Press the button Enter so many times until the
desired adjustment is displayed:
OFF no backlight compensation
BLC1 objects in the central picture area are
brightened up, shown by the inserted white
field on the monitor.
BLC2 objects in the lower central picture
area are brightened up.
BLC3 objects in the lower half of the picture
are brightened up.
BLC4 objects in the upper half of the picture
are brightened up.
USER SET The picture area in which objects
are to be brightened up can be defined by
yourself:
a) Select the menu item SET with the button
b) Press the button Enter. A small white field
appears in the centre of the screen and the
request SET START POINT flashes.
c) With the cursor buttons
move the white field to one corner of the
area to be brightened up.
.
.
(2) so that it flashes.
or .
,
