Please unfold page 3. Thus you will always be able
GB
to see the operating elements and connections
described.
1

Operating Elements and Connections

1.1 Camera
1 Channel switches
1
2
Channel 1
2.414 GHz
2 Light sensor, switches on the IR LEDs (3) in case the
illumination is too poor and switches the camera to
black-and-white reproduction
3 Infrared light diodes (IR LEDs)
4 Sunshield
5 Front housing sleeve, can be screwed off for channel
adjustment
6 Antenna connection (SMA jack)
7 Transmitting antenna
8 Camera support
9 Low voltage inline jack for connection of the supplied
camera power supply unit
10 Low voltage plug (3.5/1.35 mm) of the camera power
supply unit
8
Channel 2 Channel 3
2.432 GHz 2.450 GHz
1.2 Receiver
11 Reception antenna
12 Antenna connection (SMA jack)
13 LEDs to indicate the adjusted channel
14 Button SET for channel adjustment
15 POWER switch
16 Connection jack DC12V for the supplied power sup-
ply unit of the receiver
17 AUDIO output (phono)
18 VIDEO output (phono)
Channel 4
19 Low voltage plug (5.5/2.1 mm) of the power supply
2.468 GHz
unit of the receiver
2

Safety Notes

The units (camera, receiver, and power supply units) cor-
respond to all required directives of the EU and are
therefore marked with
WARNING The power supply units are supplied with
Please observe the following items in any case:
The camera must not be operated near cardiac pace-
makers (minimum distance 25 cm) and medical appli-
ances. The electromagnetic radiation may lead to
interference.
.
hazardous mains voltage (230 V~). Leave
servicing to skilled personnel only. In-
expert handling may cause an electric
shock hazard.
