HYDRIM M2 G4 Installation Instructions
Connect machine to power supply
Electrical supply requirements:
• Dedicated 16A independent supply (see
Note 1 below). OR
• Standard domestic outlet
• Voltage: 230 – 240 VAC ±10%,
single-phase, 50 Hz or 60 Hz, 13A
• Located within 1.50 metres maximum
• Supply location (see notes below)
• Power cord routing (see note below)
NOTE 1 – The HYDRIM M2 G4 is supplied with a domestic fused plug as standard.
A dedicated hard wired 16A supply can also be used.
NOTE 2 - Due to the power requirements of the HYDRIM, (Rated load 2.5 kW), it is advised
that no other equipment is connected to the same supply outlet.
NOTE 3 - Power supply outlet should be adjacent to the machine and not behind it.
The cable should be routed away from the back panel and hot water inlet hose.
Page 9
